Thông tin chi tiết
| Details IEC |
| Standards |
| IEC 61439-1:2020 |
| Electrical data IEC |
| rated voltage (IEC) AC: |
690 V |
| rated frequency (IEC): |
50 / 60 Hz |
| rated isolation voltage Ui AC: |
800 V |
| rated surge voltage Uimp : |
6 kV |
power dissipation of the article:
The power dissipation at a typical load of 80 % results to 0.0 W.
(The power dissipation at full load would be 0.0 W.)
| Supplementary data IEC |
|
The following values have been verified with tests under certain conditions. Please ask Wöhner for this conditions before designing your panel.
|
| min. permitted operation temperature |
-40°C |
short-circuit capacity :
Ipk = min. 35 kA (2 busbar supports in 250 mm distance) |
| Mechanical data |
| W x H x D: |
14 x 264 x 67 |
| weight: |
16.7 kg/100 |
| poles: |
3-pole |
| for busbars: |
3x (12, 20, 30 x 10) und 2x (12, 20, 25 x 5, 10) |
| Material properties |
| halogen-free: |
Yes |
