One-Piece Consoles In Mild Steel, MPG
Category:
nVent Hoffman
|
Code:
MPG
The mild steel compact console, MPG, in a IP 55/56 protection degree is available off the shelf. It has a hinged desk panel, and the ergonomic design allows for easy installation and access to HMI-equipment. It also increases the mounting space available. Stainless steel top panels may be used as an alternative when the console is exposed chemical agents, etc.
Thông tin chi tiết
Features
Material: Body and door: 1.5 mm mild steel. Rear panel. 1.5 mm mild steel. Bottom plates: 1.2 mm galvanized steel. Mounting plate: 2.5 mm galvanized steel.
Body: Folded and seam welded. Console construction includes a base that provides a distance between the floor and the lower part of the door/s, acting as an integrated plinth.
Doors and panels: Single folded surface mounted with hinges, allowing left and right-hand opening to base door. Angle 12° from horizontal. Concealed hinges on top edge allow 90° opening. Panel held open by self engage/self release mechanical panel stay. Double door on 1200 and 1600 mm wide base units.
Mounting plate: Standard mounting plate in base unit.
Lock: Double-bit 3 mm locks for top panel. For base, two double-bit 3 mm locks.
Cable inlet: Bottom opening for cable access. Bottom plates for cable glanding supplied as standard.
Earthing: M8 threaded studs on body, door, top panel and rear panel.
Finish: RAL 7035 structured powder coating.
Protection: Single door: IP 66, TYPE 4, 12, 13, IK 10. Double door: IP 55, TYPE 12, 13, IK 10.
Delivery: Mounting plate and suitable nuts and washers for earthing. The console is delivered on a wooden pallet.
